- Compliant IEEE 802.3, IEEE 802.3u, IEEE802.3ab, IEEE802.3x standards
- Supports IEEE802.3af, IEEE802.3at, Hi-PoE standards
- Supports normal working mode, port isolation (VLAN) mode, monitoring mode, network extend mode.
- Supports Store-and-Forward
- 24*10/100Mbps ports, 1*Gigabit Combo port, support port auto flipping (Auto MDI / MDIX)
- Port 1-2 support the maximum power of 60W, PoE output total power up to 190W
- Supports IEEE802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode
- 4K entry MAC address table with auto-learning and auto-aging
- LED indicators for monitoring power, link and activity
- Standards : IEEE 802.3, IEEE 802.3u, IEEE802.3ab, IEEE802.3z,IEEE802.3x, IEEE802.3af, IEEE802.3at, Hi-PoE
- Interface : 24 x 10/100Mbps RJ45 / 1 x Gigabit Combo (RJ45/SFP)
- Transfer Method : Store-and-Forward
- Switching Capacity : 6.8Gbps
- Packet Forwarding Rate : 5.06Mbps
- Packet Buffer : 4Mbit
- PoE Ports(RJ45) : Port 1/2 : Hi-PoE/PoE+/PoE / Port 1-24 : PoE+/PoE
- Power Pin Assignment : 1 to 2 port: 1/2/4/5 (+), 3/6/7/8 (-) / Other PoE port: 4/5 (+), 7/8 (-)
- PoE Total power : 190W
- Default mode : All ports can communicate with each other
- Isolation mode : PoE port cannot communicate with each other, but can communicate with the uplink Combo port
- CCTV mode : 1 to 8 ports support port priority, optimize port cache, switch all ports can communicate with each other
- Extender mode : 1 to 8 port rate down to 10Mbps, the farthest transmission distance of up to 250 meters, all ports can communicate with each other
- Indicators : Per Device / Power: Green MAX : Red
- Per Port : Link/Act: Green PoE: Yellow
- Power Supply : AC 100V~240V 50/60HZ
- Dimensions (W × D × H) : 340*200*43 mm
- Operating Temperature: 0°C ~ 45°C
- Storage Temperature: -40°C ~ 70°C
- Operating Humidity: 10%~90% RH No condensation
- Storage humidity: 5%~90% RH No condensation
