Regular price
€1.599,00 EUR
Regular price
€0,00 EUR
Sale price
€1.599,00 EUR
Unit price
per
Tax included.
0 in Stock. Available online!
Couldn't load pickup availability
Technical Specifications
Features
| Number of Channels | 5 |
| THX | No |
| DTS | No |
| Dolby | No |
| DSD (SA-CD)/Neural | No |
| SRS | No |
| HDCD Decoder | No |
| Current Feedback Topology | Yes |
| Discrete Amplification | Yes |
| Power Transformer | Large Capacity EI |
| D/A Conversion | No |
| Digital Signal Processing | No |
| Video Off (Pure Direct) | No |
| Source Direct | No |
| Source Direct | Steel |
| Variable X-over | Steel |
| Display Off | Blue LED Illumination off mode available |
| Video Up-conversion | No |
| Auto Calibration by MIC | No |
| Satellite Radio Ready | No |
| AM/FM Tuner | No |
| Bass Redirection | No |
| Lip-sync (digital audio delay) | No |
| Software Upgradable | No |
In/Outputs
| HDMI In | No |
| Component In | No |
| S-Video In | No |
| Composite In | No |
| HDMI Out | No |
| Component Out | No |
| S-Video Out | No |
| Composite Out | No |
| Analog L&R In | No |
| Analog L&R Out | No |
| Digital Optical In | No |
| Digital Coaxial In | No |
| Digital Optical Out | No |
| Digital Coaxial Out | No |
| Other | No |
| Pre-Amplifier Out | No |
| Main Amplifier In | Balanced & Unbalanced: 5ch (Exclusive use by a selector switch.) |
| Multi-Channel In | No |
| Multi-Room Audio Out | No |
| Multi-Room Video Out | No |
| Multi-Room Speaker Out | No |
| Networking | No |
| External control | No |
| DC Triggers | 1 In / 1 Out |
| D-Bus Remote (RC-5) In/Out | 1 - 1 |
| Flasher In/IR Receiver In/Emitter out | 1/0/0 |
| Front Panel A/V Inputs | No |
| Headphone Out | No |
| AC Outlets (Switched/Unswitched) | No |
Specifications
| Power Output | 140W (20Hz-20kHz, 0.08%) |
| S/N Ratio | 105dB |
| Freq. Response (Analog In) | 8Hz-100kHz (+/- 3dB) |
| Freq. Response (Dig In) | No |
| Frequency Range | No |
| S/N Ratio (Mono/Stereo) | No |
| Frequency Range | No |
| S/N Ratio | No |
| Video Freq. Response (Component) | No |
| Video Freq. Response (Composit, S-Video) | No |
| Signal to Noise | No |
General
| Color | Black |
| Front Panel | Aluminum/Glass-reinforced resin |
| Remote Control | No |
| Power Requirement | No |
| Power Consumption | 660W (Standby: 0.2W) |
| Dimensions W x H x D (Inchs) | 17-3/8 x 7-3/16 x 15-1/8 |
| Weight (lbs) | 34.6 |
